150A Mega-Fuse with melt element diffusion tin-drop technology. Complies with international standards, such as ISO 8820-5 and JASO D612, as well as REACH and RoHS. Mega fuses provide a compact alternative to ANL fuses. This is the 32V version.150A Blade Fuse Megafuse
Shipping costs for this product are at the low rate.

Mega fuses provide a compact alternative to ANL fuses. This is the 32V version.

Complies with international standards, such as ISO 8820-5 and JASO D612, as well as REACH and RoHS.
Features melt element diffusion tin-drop technology.
Element visible from both sides.
Thermoplastic, heat-resistant, color-coded housing.
Equipped with M8 holes at 51mm spacing.
Values marked in OCR font on both sides of the color-coded housing.
Maximum melting capacity of 2000A at 32V DC.
Maximum tightening torque: 12Nm ± 1Nm.

Technical Specifications:
Housing: PA6T, color-coded with transparent PAR viewing window.
Element: Tinned copper alloy with integrated thermal element.
Hole: M8 at 51mm spacing.
Max Tightening Torque: 12Nm ± 1Nm.
Max Melting Capacity: 2000A @ 32V DC.
Dimensions: 68.0 mm x 18.3 mm.
MEGA Fuse 32V.
